ASCENT Wood - Red

Mid Launch / Mid-Low Spin

ASCENT™ Red helps you raise your launch angle while controlling spin and face deflection for higher ball flight with long descent and roll out. Golfers looking to improve flight apex often turn to added loft or a more active shaft, yet both can lead to more spin and bigger misses. ASCENT models counter this with an integrated Impact Stabilization Zone. This unique enhancement – created by pairing a strategically-placed section of increased stiffness with a focused area of heavier, tungsten-infused prepreg – preserves the shaft’s lively feel and higher launch angle while maintaining stability and maximum energy transfer at impact. You get a more active profile, more kick, and higher ball speed while still getting the accurate, penetrating flight needed for maximize distance.

For additional information on the ASCENT™ family of shafts, Impact Stabilization, and FlyDrive, click here.

  • Specifications
    Shaft NameFlexLength (in)Weight (g)Tip O.D. (in)Tip Length (in)Butt O.D. (in)Torque (degrees)Kick Pt.
    ASCENT™ 40R246470.3353.00.5967.4MID
    ASCENT™ 40R46480.3353.00.6007.1MID
    ASCENT™ 40S46520.3353.00.6046.9MID
    ASCENT™ 50R46540.3353.00.6005.7MID
    ASCENT™ 50S46580.3353.00.6045.5MID
    ASCENT™ 50X46610.3353.00.6065.4MID
    ASCENT™ 60S46650.3353.00.6124.9MID
    ASCENT™ 60X46680.3353.00.6144.8MID
    ASCENT™ 60TX46690.3353.00.6164.7MID
    ASCENT™ 70S46740.3353.00.6063.8MID
    ASCENT™ 70X46760.3353.00.6103.7MID
    ASCENT™ 70TX46780.3353.00.6143.6MID
    ASCENT™ 80TX46870.3353.00.6142.9MID
  • Technology

    IMPACT STABILIZATION ZONE

    Impact Stabilization minimizes deflection and face rotation using a tungsten-infused prepreg to create a heavier zone just below a stiffer section of the tip. Heavier mass of ISZ also contributes to added ball speed.
  • Fitting
    Driver Speed (mph)/Driver Carry (yds)<80/<21081-90/210-23091-105/241-259>106/>260
    ASCENT™ 40R2RS
    ASCENT™ 50RSX
    ASCENT™ 60SX/TX
    ASCENT™ 70SX/TX
    ASCENT™ 80TX
  • Tip Trimming Information
    Driver 3 Wood5 Wood7 Wood9 Wood
    0"0.5"0.75"1.0"1.0"
